Lathem Master Clock
AQMSTR-00X8E (LTR512)


Master clocks for schools, manufacturing, airports, hospitals, etc. Replaces Lathem LTR512

Retail Price: $1,199.00
Our Price: $1,025.00
Shipping will be calculated during checkout.

master clock

Accessories & Supplies:

DetailsIDProduct NameDescriptionPriceAdd To Cart
Click 2 Lathem Analog child clockSS12xxx Arabic wall Clock$162.00
Click 752 Low Voltage Power SupplyLTR512 PS8-24VAC AQMSTER-00X8E$261.95
Click 6 Lathem PS8-24B2 new P/N YPS6-24Lathem 2 wire power booster$239.00
Click 8 Lathem PS8-24B3 new p/n YPB6-24DC-3W-WEBLathem 3 wire Impulse power booster$0.01




Lathem Master Clock AQMSTR-008XE replaces Lathem LTR512

  • Dimensions:  8.5"high x 11" Wide x 6.5" deep Weight: 4 lbs.
  • 5 Year Warranty
  • UL/cUL rated
  • 100% FCC compliant
  • Programmable events:  9,999.  Schedules:  99
  • Input Voltage: 120vac 50/60Hz
  • Output:  120vac
    **  Requires PS8-2412 Power Supply for low voltage clocks
  • Input Frequency: 60Hz
  • Input Power: 10 Watts Max
  • Nominal Power:  5 Watts
  • Clock circuit fuses:  8 amps, 250vac, subminiture
  • Fuse: 2.5 amps, 250vac
  • Memory:  CR2032 lithium battery
  • Standby timekeeping:  10 years
  • Optional signal circuits: Dry contacts raged at 250vac, continious:  7.5amps resistive, 5 amps inductive
  • Program Memory Retention: 10 year - Lithium Battery Backup
  • Battery: 10 Year Lithium
  • Operating Temperature: 32° - 140° F (0°C - 79.4°C)
  • Operating Humidity 5% - 85% RH, non-condensing
  • Accuracy:  +- 1 minute per year.
  • Synchronzation:  NTP servers, your network, or manally
  • Communication:  Ethernet
  • Automatically adjusts for Daylight Savings and Leap Year
  • Keypad:  16 button tactile feedback membrane switch
  • Interface:  Remote Connect web server, wich enables event programming, circiut selection and activation and other system features remotely accessed via web browser from computer. This means that it is unaffected by Windows or Apple operating systems.

Lathem AQMSTR Manuals and Technical Support Instructions



AQMSTR Owners Manual
